ENGINEERING LINK ANALYSIS

ELA will add ISR integration and common intelligence picture to US and foreign partners

IME built Engineering Link Analysis (ELA) to fulfill the Army’s geospatial needs for both disconnected, intermittent, and low bandwidth (DIL) and connected environments. ELA provides DIL environment warfighters mapping technology on any laptop, tablet, or mobile device through thin-client mapping overlaid with intelligence information, providing a holistic Common Intelligence Picture (CIP) and user needs-driven, and easier-to-learn and -use platform while disseminating data.



ELA's technical approach is to provide a high-performance, thin-client map with overlays of intelligence data in disconnected, low bandwidth, and intermittent bandwidth modes. Our technology stack includes CesiumJS, HTML5, Cesium ION, and Microsoft SQL 2012 R2. Our development is in C# and Java Script with Apache for real-time calls to the database.

ELA brings mapping technology to the 'Last Tactical Mile' with Security Forces Assistance Brigade during deployments to CENTCOM, AFRICOM, and EUCOM.

FREE DEMO
Simple meets powerful.

Disconnected and Low Bandwidths

Intelligence is no longer restricted by disconnected and low bandwidth environments.

IPB Graphic.png

ISR and Drone Visualization

ELA is an integration powerhouse, bringing in cutting edge drone ISR feeds for direct ingestion, even in low bandwidth environments

3D Mapping

Common Intelligence Picture

Intelligence is unified in all environments through ELA


Mixed Reality
Mixed Reality

press to zoom
Future Vertical Lift
Future Vertical Lift

press to zoom
Last Tactical Mile
Last Tactical Mile

press to zoom
Mixed Reality
Mixed Reality

press to zoom
1/6
CURRENT ELA IMPLEMENTATION

  • Employed with the Security Forces Assistance Brigades supporting CENTCOM, AFRICOM and SOUTHCOM

  • Letters of Justification identifying the gaps and operational warfighter needs (Commander, 2SFAB and Commander, 4SFAB)

  • Interoperable with WinTAK, ATAK and  DCGS-A platforms

  • Technical Readiness Level of 9

  • Certificate of Networthiness on SIPR and NIPR

ELA achieved Technical Readiness Level (TRL) 7-9 in January 2019 and is fully fielded in Afghanistan


SFAB Drone Training.jpg

AUTONOMOUS UNMANNED AERIAL SYSTEMS


As part of the ELA kit, IME equips and trains personnel on unmanned aerial systems.

ELA brings mapping technology to the 'Last Tactical Mile' and has been deployed to various locations around the globe with the Security Forces Assistance Brigades.
